EXG-200 Specifications

General

Dimensions

4.05 in x 7.67 in x 2.16 in
(10.3 cm x 19.5 cm x 5.5 cm)

Weight

1.677 lbs (0.76 kg)

Battery

Rechargeable lithium-ion battery pack (7.2 V, 6.4 Ah, 46 Wh)

Battery
Run Duration, Charge Time

Typical duration: 3-4 hours with all hardware powered on

8+ hours if wired test port is disabled

Typical charge time: 2-4 hours

Display

5.0-inch color LCD with capacitive touchscreen (720 x 1280 pixels)

Host
Interfaces

RJ-45 Cable Test and Management Port

USB Type-A Port

USB Type-C On-the-Go Port

SD Card Port

Supports Micro SD card storage

Memory

Approximately 8 GB available for storing test results and user applications

Charging

USB Type-C 45-W adapter:
AC Input Power 100-240 V, 50-60 Hz; DC Output Power 15 V (3 A)

Media Access

Copper: 10M/100M/1G/2.5G/5G/10G

Fiber SFP Adapters: 1G/10GBASE-X

Supported IEEE Standards

Wired: 802.3/ab/ae/an/bz/i/u/z

Wi-Fi: 802.11a/b/g/n/ac

PoE: 802.3af/at/bt, Class 0-8 and UPOE

Cable Test

Pair lengths, opens, shorts, splits, crossed, straight through, and WireView ID

Tone Generator

Digital tone: [455 KHz];
Analog tones: [400 Hz, 1 KHz]

LEDs

2 LEDs (Activity and Link Indicators)

Wireless

EtherScope nXG has two internal Wi-Fi Radios:

  • Wi-Fi Testing – 4x4 Dual-band 802.11ac Wave 2 wireless radio

  • System Wi-Fi, Bluetooth, and Management – 1x1 Dual-band 802.11ac Wave 2 + Bluetooth 5.0 and BLE wireless radio

Both are IEEE 802.11a/b/g/n/ac compliant.

4x4 Wi-Fi Radio for Testing

Applicant's Name

NetAlly

Model Number

BCM43465

Manufacturer

LITE-ON Technology Corporation

Manufacture Date

2017

Country of Origin

Taiwan

Security

64/128-Bit WEP Key, WPA, WPA2, 802.1X (TKIP, AES)

Regulatory Domain

World Mode

Antenna Gain

1.1 dBi peak in the 2.4-GHz band; 3.2 dBi peak in the 5-GHz band
Data Rates

802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11b: 1, 2, 5.5, 11 Mbps

802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n 20 MHz: 7.2, 14.4, 21.7, 28.9, 43.3, 57.8, 65, 72.2, 86.7 Mbps

802.11n 40 MHz: 15, 30, 45, 60, 90, 120, 135, 150 Mbps

802.11ac 20 MHz: 7.2, 14.4, 21.7, 28.9, 43.3, 57.8, 65, 72.2, 86.7 Mbps

802.11ac 40 MHz: 15, 30, 45, 60, 90, 120, 135, 150, 180, 200 Mbps

802.11ac 80 MHz: 32.5, 65, 97.5, 130, 195, 260, 292.5, 325, 390, 433 Mbps

802.11ac 160 MHz: 65, 130, 260, 390, 520, 585, 650, 780, 867 Mbps

Operating Frequencies

The EtherScope nXG receives on all of the frequencies in every country, but transmits only on the frequencies and channels allowed in the country.

These are the center frequencies of the channels that the Wi-Fi radio supports.

2.4-GHz band: 2.412 – 2.484 GHz (channels 1 through 14)

5-GHz band: 5.150 – 5.825 GHz (channels 34, 36, 38, 40, 42, 44, 46, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 144, 149, 153, 157, 161, 165)

Modulation

802.11b: DBPSK (1 Mbps), DQPSK (2 Mbps), CCK (5.5 and 11 Mbps)

802.11g/n: DBPSK, DQPSK, OFDM, BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM (proprietary)

Receive Sensitivity (Minimum)

6 Mbps: -90 dBm

54 Mbps: -71 dBm

802.11n 20 MHz: -89 dBm (MSC 0/8)

802.11n 40 MHz: -86 dBm (MSC 0/8)

VHT20 MCS 8: -63 dBm

VHT40 MCS 9: -60 dBm

VHT80 MCS 9: -57 dBm

System 1x1 Wi-Fi/Bluetooth Adapter for Management

Applicant's Name

NetAlly

Model

Bluebean-A

Manufacturer

8devices

Manufacture Date

2019

Country of Origin

United States

Security

64/128-Bit WEP Key, WPA, WPA2, 802.1X (TKIP, AES)

Regulatory Domain

World Mode

Antenna Peak Gain

+2.27 dBi in the 2.4-GHz band

+5.18 dBi in the 5-GHz band
Data Rates

802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11b: 1, 2, 5.5, 11 Mbps

802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n 20 MHz: 7.2, 14.4, 21.7, 28.9, 43.3, 57.8, 65, 72.2, 86.7 Mbps

802.11n 40 MHz: 15, 30, 45, 60, 90, 120, 135, 150 Mbps

802.11ac 20 MHz: 7.2, 14.4, 21.7, 28.9, 43.3, 57.8, 65, 72.2, 86.7 Mbps

802.11ac 40 MHz: 15, 30, 45, 60, 90, 120, 135, 150, 180, 200 Mbps

802.11ac 80 MHz: 32.5, 65, 97.5, 130, 195, 260, 292.5, 325, 390, 433.3 Mbps

Operating Frequencies

The EtherScope nXG receives on all of the frequencies in every country, but transmits only on the frequencies and channels allowed in the country.

These are the center frequencies of the channels that the Wi-Fi radio supports.

2.4-GHz band: 2.412 – 2.484 GHz (channels 1 through 14)

5-GHz band: 5.150 – 5.825 GHz (channels 34, 36, 38, 40, 42, 44, 46, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 144, 149, 153, 157, 161, 165)

Modulation

802.11a: BPSK (6 and 9 Mbps), QPSK (12 and 18 Mbps), 16 QAM (24 and 36 Mbps), 64 QAM (48 and 54 Mbps), OFDM

802.11n/ac: BPSK (MCS0), QPSK (MCS1 and MCS2), 16 QAM (MCS3 and MCS4), 64 QAM (MCS5, 6, and 7), OFDM

802.11ac: 256 QAM (MCS8 and MCS9), OFDM

802.11b: DBPSK, BPSK (1 and 2 Mbps), QPSK (2 Mbps), CCK (5.5 and 11 Mbps)

802.11g: BPSK (6 and 9 Mbps), QPSK (12 and 18 Mbps), 16 QAM (24 and 36 Mbps), 64 QAM (48 and 54 Mbps), OFDM

Bluetooth v5 and BLE

Frequency Range: 2.402 – 2.480 GHz

Max TX power: 14 dBm (4 dBm BLE)

External Directional Antenna Accessory

  • Minimum gain: 5.0-dBi peak in the 2.4-GHz band and 7.0-dBi peak in the 5-GHz band

  • Reverse-polarity SMA plug

  • Antenna frequency range: 2.4 – 2.5 and 4.9 – 5.9 GHz

  • External antenna port is receive-only (no transmit).

Environmental Specifications

Operating
Temperature

32ºF to 113ºF (0ºC to +45ºC) NOTE: The battery will not charge if the internal temperature of the unit is above 113ºF (45ºC).

Operating relative humidity (% RH without condensation)

90% (50ºF to 95ºF; 10ºC to 35ºC) 75% (95ºF to 113ºF; 35ºC to 45ºC)

Storage Temperature

-4ºF to 140ºF (-20ºC to +60ºC)

Shock and vibration

Meets the requirements of MIL-PRF-28800F for Class 3 Equipment

Safety

IEC 61010-1:2010: Pollution degree 2

Altitude

Operating: 4,000 m; Storage: 12,000 m

EXG-200 Certifications and Compliance

CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

Conforms to relevant European Union directives.

Conforms to relevant Australian Safety and EMC standards.

Complies with 47 CFR Part 15 requirements of the U.S. Federal Communications Commission.

Listed by the Canadian Standards Association.

Industry Canada Class A emission compliance statement: This Class A digital apparatus complies with Canadian ICES-003. Avis de conformité à la réglementation d'Industrie Canada Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.

This device is not capable of transmitting in 5600-5650 MHz. This restriction is for the protection of Environment Canada’s weather radars operating in this band.

U-NII devices operating in the 5.25-5.35 GHz and 5.47-5.725 GHz band, without radar detection are restricted to use indoors.

Contains FCC IDs

WA7-43465, WA7-9377

Contains IC IDs

6627C-43465, 6627C-9377

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).

L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1. L’appareil ne doit pas produire de brouillage; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.

Absorption Rate (SAR) information: This device meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health.

FCC RF Exposure Information and Statement: The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. This device was tested for typical body-worn operations with the back of the handset kept 0 cm from the body. To maintain compliance with FCC RF exposure requirements, use accessories that maintain a 0 cm separation distance between the user's body and the back of the handset. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided.

Body-worn Operation: This device was tested for typical body-worn operations. To comply with RF exposure requirements, a minimum separation distance of 0 cm must be maintained between the user's body and the handset, including the antenna. Third-party belt-clips, holsters, and similar accessories used by this device should not contain any metallic components. Body-worn accessories that do not meet these requirements may not comply with RF exposure requirements and should be avoided. Use only the supplied or an approved antenna.

EMC

IEC 61326-1:2013: Basic Electromagnetic Environment; CISPR 11: Group 1, Class A

Group 1: Equipment has intentionally generated and/or uses conductively-coupled radio frequency energy that is necessary for the internal function of the equipment itself.

Class A: Equipment is suitable for use in all establishments other than domestic and those directly connected to a low-voltage power supply network that supplies buildings used for domestic purposes. There may be potential difficulties in ensuring electromagnetic compatibility in other environments due to conducted and radiated disturbances.

EU Compliance

This device complies with the following EU Directives: Directives 2014/53/EU, 2014/35/EU, and 2014/30/EU.

This device complies with RF specifications when the device is used at 0 mm from your body. Maximum measured SAR was 2.21 W/kg body; EU limit is 4.0 W/kg.

Accessory Information:

Adapter Model No.: FSP045-A1BR

Input: AC 100-240 V, 50/60 Hz 1.2 A

Output: DC 15 V, 3 A

Battery: 3250 mAh, 7.2 V 6.4 Ah

Wi-Fi: 2412 MHz-2472 MHz, 5180 MHz-5240 MHz, 5725 MHz - 5875 MHz

Bluetooth/BLE: 2402 MHz - 2480 MHz
เครื่องโทรคมนาคมและอุปกรณ์นี้ มีความสอดคล้องตามข้อกำหนดของ กสทช. (This telecommunication equipment conforms to the requirements of NBTC.)
