LinkRunner AT Specifications

In this Topic

General

Environmental Specifications

Certifications and Compliance Statements



General

Dimensions

4.02 in x 7.72 in x 1.65 in
(10.2 cm x 19.6 cm x 4.2 cm)

Weight

1.06 lbs (0.48 kg)

Battery

Rechargeable lithium-ion battery pack (3.63 V, 9.75 Ah, 36.39 Wh)

Battery Run Duration,
Charge Time

Typical run duration: 9 hours

Typical charge time: 3 hours

Display

5.0-inch color LCD with capacitive touchscreen (720 x 1280 pixels)

Host
Interfaces

RJ-45 Ethernet test port
RJ-45 cable test port
(1) USB Type-A Port
(1) USB Type-C On-the-Go Port

Memory

Approximately 8 GB available for storing test results and user applications

Charging Adapter

USB Type-C 65-W adapter:
AC Input Power 100-240 V, 50-60 Hz; DC Output Power 15 V (3 A)

PoE Charging

 802.3 af/at

Supported IEEE Standards

Wired: 802.3/ab/i/u/z, 1000 BASE-T
PoE: 802.3af/at/bt Class 0-8, UPOE
Fiber: 1000BASE-X, SFP SX/LX/ZX

LEDs

1 LED (Battery Status Indicator)

Environmental Specifications

Operating
Temperature

32ºF to 113ºF (0ºC to +45ºC) NOTE: The battery will not charge if the internal temperature of the unit is above 113ºF (45ºC).

Operating relative humidity (% RH without condensation)

90% (50ºF to 95ºF; 10ºC to 35ºC) 75% (95ºF to 113ºF; 35ºC to 45ºC)

Storage Temperature

-4ºF to 140ºF (-20ºC to +60ºC)

Shock and vibration

Meets the requirements of MIL-PRF-28800F for Class 3 Equipment

Safety

IEC 61010-1:2010: Pollution degree 2

Altitude

Operating: 4,000 m; Storage: 12,000 m

EMC

 IEC 61326-1: Basic Electromagnetic Environment
CISPR 11: Group 1, Class A
Group 1: Equipment has intentionally generated and/or uses conductively-coupled radio frequency energy that is necessary for the internal function of the equipment itself.
Class A: Equipment is suitable for use in all establishments other than domestic and those directly connected to a low-voltage power supply network that supplies buildings used for domestic purposes. There may be potential difficulties in ensuring electromagnetic compatibility in other environments due to conducted and radiated disturbances.

Certifications and Compliance Statements

CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

Complies with 47 CFR Part 15 requirements of the U.S. Federal Communications Commission.

Conforms to relevant Australian Safety and EMC standards.

Listed by the Canadian Standards Association.

Conforms to relevant European Union directives.
Complies with United Kingdom and European Economic Area radiation exposure limits.
Conforms to relevant South Korean EMC Standards.

Additional South Korean EMC Standards Information

Electromagnetic Compatibility. Applies to use in Korea only. Class A Equipment (Industrial Broadcasting & Communications Equipment) [1] [1] This product meets requirements for industrial (Class A) electromagnetic wave equipment and the seller or user should take notice of it. This equipment is intended for use in business environments and is not to be used in homes.

Caution: Any changes or modifications made to the equipment without the approval of man- ufacturer could void the user’s authority to operate this equipment.

The device is for indoor use. This equipment may only be operated indoors. Operation outdoors is in violation of 47 U.S.C. 301 and could subject the operator to serious legal penalties.

The operation of this device is prohibited on oil platforms, cars, trains, boats, and aircraft, except that operation of this device is permitted in large aircraft while flying above 10,000 feet. Operation of transmitters in the 5.925-7.125 GHz band is prohibited for control of or communications with unmanned aircraft systems.

Industry Canada Class A emission compliance statement: This Class A digital apparatus complies with Canadian ICES-003. Avis de conformité à la réglementation d'Industrie Canada Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada. This device is not capable of transmitting in 5600-5650 MHz. This restriction is for the protection of Environment Canada’s weather radars operating in this band.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

L’exploitation est autorisée aux deux conditions suivantes: 1. L’appareil ne doit pas produire de brouillage; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.

Class A: Equipment is suitable for use in all establishments other than domestic and those directly connected to a low-voltage power supply network that supplies buildings used for domestic purposes. There may be potential difficulties in ensuring electromagnetic compatibility in other environments due to conducted and radiated disturbances.

This device complies with the following EU Directives: Directives 2014/53/EU, 2014/35/EU, and 2014/30/EU.

Accessory Information:

Adapter Model No.: FSP065-A1BR3

Input: AC 100-240 V, 50/60 Hz 1.2 A

Output: DC 15 V, 3 A
