LinkRunner 10G Specifications

These specifications apply to LinkRunner 10G models 100 and 200.

General

Dimensions

4.05 in x 7.67 in x 2.16 in
(10.3 cm x 19.5 cm x 5.5 cm)

Weight

1.677 lbs (0.76 kg)

Battery

Rechargeable lithium-ion battery pack (7.2 V, 6.4 Ah, 46 Wh)

Battery
Run Duration, Charge Time

Typical duration: 3-4 hours

Typical charge time: 2-4 hours

Display

5.0-inch color LCD with capacitive touchscreen (720 x 1280 pixels)

Host
Interfaces

RJ-45 Cable Test and Management Port

USB Type-A Port

USB Type-C On-the-Go Port

SD Card Port

Supports Micro SD card storage

Memory

Approximately 8 GB available for storing test results and user applications

Charging

USB Type-C 45-W adapter:
AC Input Power 100-240 V, 50-60 Hz; DC Output Power 15 V (3 A)

Media Access

Copper: 10M/100M/1G/2.5G/5G/10G

Fiber SFP Adapters: 1G/10GBASE-X

Supported IEEE Standards

Wired: 802.3/ab/ae/an/bz/i/u/z

PoE: 802.3af/at/bt, Class 0-8 and UPOE

Cable Test

Pair lengths, opens, shorts, splits, crossed, straight through, and WireView ID

Tone Generator

Digital tone: [455 KHz];
Analog tones: [400 Hz, 1 KHz]

LEDs

2 LEDs (Activity and Link Indicators)

Certifications and Compliance

CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.

Conforms to relevant European Union directives.

Conforms to relevant Australian Safety and EMC standards.

Complies with 47 CFR Part 15 requirements of the U.S. Federal Communications Commission.

Listed by the Canadian Standards Association.

Industry Canada Class A emission compliance statement: This Class A digital apparatus complies with Canadian ICES-003. Avis de conformité à la réglementation d'Industrie Canada Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.

This device is not capable of transmitting in 5600-5650 MHz. This restriction is for the protection of Environment Canada’s weather radars operating in this band.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

L’exploitation est autorisée aux deux conditions suivantes : 1. L’appareil ne doit pas produire de brouillage; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.

EMC

IEC 61326-1:2013: Basic Electromagnetic Environment; CISPR 11: Group 1, Class A

Group 1: Equipment has intentionally generated and/or uses conductively-coupled radio frequency energy that is necessary for the internal function of the equipment itself.

Class A: Equipment is suitable for use in all establishments other than domestic and those directly connected to a low-voltage power supply network that supplies buildings used for domestic purposes. There may be potential difficulties in ensuring electromagnetic compatibility in other environments due to conducted and radiated disturbances.

Accessory Information:

Adapter Model No.: FSP045-A1BR

Input: AC 100-240 V, 50/60 Hz 1.2 A

Output: DC 15 V, 3 A

Battery: 3250 mAh, 7.2 V 6.4 Ah
